Description
The NMB 08025DA-24P-BU is a high-performance 24V DC axial fan, precisely measuring 80mm x 80mm x 25mm, manufactured by NMB Technologies Corporation. This fan is engineered for demanding cooling applications that require powerful airflow and static pressure. It features robust ball bearings, ensuring a reliable operational lifespan of 70,000 hours at 40°C. This fan operates at a high speed of 7500 RPM, delivering a substantial 80 CFM of airflow and generating considerable static pressure of 0.85 inches of H2O. Due to its high performance, it produces a noise level of 58 dBA. Equipped with 4-wire leads, this model includes both PWM control for precise speed adjustment and a tachometer output for real-time RPM monitoring. The NMB 08025DA-24P-BU is an excellent choice for cooling server equipment, networking devices, power supplies, and other high-density electronic systems where efficient, reliable, and controllable high-static pressure cooling is essential for maintaining optimal operating temperatures.
NMB brand new original 08025DA-24P-BU 24V 0.35A 8025 8CM axial current heat dissipation fan
Model: 08025DA-24P-BU
Manufacturer: NMB Technologies Corporation
Type: DC Axial Fan
Dimensions: 80mm x 80mm x 25mm
Nominal Voltage: 24V DC
Current: 0.35A
Power Consumption: 8.4W
Speed: 7500 RPM
Airflow: 80 CFM
Static Pressure: 0.85 In H2O
Noise Level: 58 dBA
Bearing Type: Ball Bearing
Life Expectancy: 70,000 Hours (at 40°C)
Termination: 4-wire leads
Frame Material: Plastic
Impeller Material: Plastic
Features: PWM Control, Tachometer, Auto Restart, Polarity Protection.
