Description
The NMB 09238RA-12Q-EU-03 is an exceptionally powerful DC Axial Cooling Fan from NMB Technologies, designed for robust and intensive thermal management. Operating on 12V DC power, it draws a substantial 3.14A of current, resulting in a 37.68W power consumption. Measuring 92mm x 92mm x 38mm, this fan is built for extremely demanding cooling applications. Equipped with 4-wire leads, it includes a speed sensor for monitoring and PWM control for precise speed adjustment, alongside a locked rotor sensor. Utilizing durable ball bearings, the fan boasts a long life expectancy of 100,000 hours at 25°C. It’s designed to operate reliably within a temperature range of -10°C to 70°C and features auto restart and polarity protection, ensuring dependable operation. Please note that specific performance metrics such as speed, airflow, static pressure, and noise level are not definitively available for a 3.14A, 4-wire variant of this precise model number and may differ from other versions.
Model Number: 09238RA-12Q-EU-03
Manufacturer: NMB Technologies
Type: DC Axial Cooling Fan
Rated Voltage: 12V DC
Operating Voltage Range: 7V to 13.8V DC
Rated Current: 3.14A
Rated Power: 37.68W
Dimensions: 92mm x 92mm x 38mm
Connector: 4-Wire Leads
Bearing Type: Ball Bearing
Life Expectancy: 100,000 hours at 25°C
Operating Temperature: -10°C to 70°C
Frame Material: Plastic
Impeller Material: Plastic
Features: Auto Restart, Locked Rotor Sensor, Speed Sensor (Tachometer), PWM Control, Polarity Protection
