Description
The NMB 12038VA-12R-EU-04 is an exceptionally powerful DC Axial Cooling Fan from NMB Technologies, designed for extreme thermal management in highly demanding applications. Operating on 12V DC power, it draws a significant 3.60A of current, resulting in a 43.2W power consumption. Measuring 120mm x 120mm x 38mm, this fan is ideally suited for cooling in high-performance servers, networking equipment, supercomputers, and industrial systems where a very large volume of air needs to be moved against high impedance. It rotates at an ultra-high speed of 7200 RPM, delivering an impressive airflow of 272 CFM and generating substantial static pressure at 1.70 inch-H2O. With a noise level of 72 dBA, it provides robust cooling. Equipped with 4-wire leads, it features PWM control for precise speed adjustment and a speed sensor (tachometer) for monitoring. Utilizing durable ball bearings, the fan boasts a long life expectancy of 100,000 hours at 25°C. It is designed to operate reliably within a temperature range of -10°C to 70°C and includes auto restart and polarity protection for dependable performance.
Model Number: 12038VA-12R-EU-04
Manufacturer: NMB Technologies
Type: DC Axial Cooling Fan
Rated Voltage: 12V DC
Operating Voltage Range: 10V to 13.8V DC
Rated Current: 3.60A
Rated Power: 43.2W
Speed: 7200 RPM
Airflow: 272 CFM
Static Pressure: 1.70 inch-H2O
Noise Level: 72 dBA
Dimensions: 120mm x 120mm x 38mm
Connector: 4-Wire Leads
Bearing Type: Ball Bearing
Life Expectancy: 100,000 hours at 25°C
Operating Temperature: -10°C to 70°C
Frame Material: Plastic
Impeller Material: Plastic
Features: Auto Restart, Speed Sensor (Tachometer), PWM Control, Polarity Protection
