Description
The NMB 15038PB-B3L-EP-00 is a high-performance AC axial fan with dimensions of 172 x 150 x 38 mm and a weight of 843 g. This fan operates on 230V, drawing 0.19 A of current and consuming 35 W of power. It provides an airflow of 212 CFM (360 m³/h) and generates a static pressure of 0.865 inch H₂O (215.5 Pa). The fan operates at a speed of 3200 RPM with a noise level of 56 dB(A).
15038PB-B3L-EP-00 Fan Parameters
Manufacturer: NMB Technologies Corporation
Model: 15038PB-B3L-EP-00
Fan Type: AC Axial Fan
Dimensions: 172 x 150 x 38 mm
Rated Voltage: 230V
Current Rating: 0.19 A
Power Consumption: 35 W
Airflow: 212 CFM (360 m³/h)
Static Pressure: 0.865 inch H₂O (215.5 Pa)
Speed: 3200 RPM
Noise Level: 56 dB(A)
Weight: 843 g
Application: The 15038PB-B3L-EP-00 is primarily used in UPS power supplies and is also suitable for cooling in high-density rack systems, power supply units, and telecommunication equipment.
