High temperature resistant fan 3.5E-230HB original new 220V Bairui AC9238 high temperature resistant ball cooling fan
Model Number: 3.5E-230HB
Manufacturer: Typically Bi-Sonic Technology Corp.
Fan Type: AC Brushless Axial Fan
Dimensions L x H x W: 92 mm x 92 mm x 38 mm
Rated Voltage: 230 VAC
Operating Frequency: 50/60 Hz
Rated Current: 0.15 A / 0.14 A
Input Power: 16 W / 14 W
Wiring: 2 Wire Leads
Bearing Type: Ball Bearing
Rotational Speed RPM: 2600 RPM / 3000 RPM
Maximum Airflow: 48.9 CFM / 55.5 CFM
Maximum Static Pressure: 0.21 in H2O / 0.27 in H2O
Noise Level: 38 dB / 43 dB
Frame Material: Metal
Impeller Blade Material: Metal
Protection Functions: Impedance protected
Operating Temperature Range: -30°C to +85°C
Expected Life: 50,000 hours
Mass: 470 g
The 3.5E-230HB is a heavy-duty 92x92x38mm AC axial fan designed for demanding cooling applications. Operating on 230 VAC at either 50Hz or 60Hz, it consumes between 14 W and 16 W of power with a current draw from 0.14 A to 0.15 A. This fan features ball bearings for reliable and long-lasting operation, with an expected life of 50,000 hours. Its all-metal construction makes it highly durable and suitable for high-temperature environments, ranging from -30°C to +85°C.
It delivers a substantial airflow of 48.9 CFM to 55.5 CFM at speeds between 2600 RPM and 3000 RPM, generating significant static pressure for effective cooling in various enclosures. With a noise level of 38 dB to 43 dB, it’s a powerful performer. The 3.5E-230HB is an excellent choice for cooling industrial control cabinets, power supplies, machinery, and other systems where robust construction, high airflow, and operation on AC mains power are essential.
