Description
The NMB 3110SB-04W-B79-E03 is a high-performance 12V DC axial cooling fan from NMB Technologies, measuring 80x80x25mm. This fan is designed for demanding thermal management applications requiring robust airflow. It operates at 0.38A (4.56W), achieving a high speed of 4000 RPM. This generates a substantial 45.9 CFM of airflow and a static pressure of 0.26 inch-H2O, making it highly effective for cooling components or enclosures with moderate airflow resistance. Equipped with durable ball bearings, it boasts an impressive life expectancy of 100,000 hours at 25°C. Its 3-wire configuration includes a locked rotor sensor for reliable monitoring of fan status, ensuring enhanced system reliability, all while operating at a noise level of 40.0 dBA.
Model Number: 3110SB-04W-B79-E03
Manufacturer: NMB Technologies Corporation
Type: DC Axial Cooling Fan
Rated Voltage: 12V DC
Operating Voltage Range: 6V to 13.8V DC
Rated Current: 0.38A
Rated Power: 4.56W
Speed: 4000 RPM
Airflow: 45.9 CFM / 1.30 m³/min
Static Pressure: 0.26 inch-H2O / 64.4 Pa
Noise Level: 40.0 dBA
Dimensions: 80mm x 80mm x 25mm
Connector: 3-Wire Leads
Bearing Type: Ball Bearing
Life Expectancy: 100,000 hours at 25°C
Operating Temperature: -10°C to 70°C
Frame Material: Plastic
Impeller Material: Plastic
Features: Locked Rotor Sensor (Tachometer Output), Auto Restart, Polarity Protection
