3314NH ebmpapst 12V DC Axial Fan

Description

The ebmpapst 3314NH is a DC Axial Fan measuring 92x92x38mm. It operates on 12VDC with a range of 6 to 15VDC. This fan draws 0.11A of current, consumes 2.6W of power, and achieves a speed of 3050 RPM. It provides an airflow of 105 m³/h (61.8 CFM) with a static pressure of 47 Pa at a noise level of 39 dB(A). It is built with a glass-fiber reinforced PA plastic for both the housing and the impeller. The fan features a durable ball bearing system and an IP40 protection level, and includes protection against reverse polarity and a blocked rotor. It is a reliable solution for cooling electronic components in a variety of industrial and telecommunication applications.

3314NH Fan Parameters
Model: 3314NH
Manufacturer: ebmpapst
Type: DC Axial Fan
Dimensions: 92 x 92 x 38 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 6 to 15 VDC
Current Draw: 0.11 A
Power Input: 2.6 W
Fan Speed: 3050 RPM
Airflow: 105 m³/h (61.8 CFM)
Static Pressure: 47 Pa
Noise Level: 39 dB(A)
Bearing Type: Ball Bearing
Protection Level: IP40
Termination: 2 Wire Leads
Housing Material: Glass-fiber reinforced PA plastic
Impeller Material: Glass-fiber reinforced PA plastic
Direction of Rotation: Clockwise, viewed toward rotor
Operating Temperature: -20 to 75 °C
Motor Protection: Protection against reverse polarity and blocked rotor
Application: Cooling electronic components in industrial and telecommunication application
