Description
The NMB 3610KL-05W-B69-X02 is a high-performance 24V DC axial cooling fan from NMB Technologies Corporation, measuring 92mm x 92mm x 25mm. Operating at a rated current of 0.26A (6.24W), this fan is designed to provide substantial airflow for various cooling applications. It achieves a speed of 3600 RPM, delivering 61.8 CFM of airflow and a static pressure of 0.229 inch-H2O, while maintaining a noise level of 44.5 dBA. Equipped with durable ball bearings, it ensures a long operational life of 50,000 hours at 25°C. The fan utilizes 3-wire leads, providing a speed sensor for monitoring its operational status, making it a reliable choice for cooling power supplies, industrial equipment, and other systems requiring effective air movement.
Model Number: 3610KL-05W-B69-X02
Manufacturer: NMB Technologies Corporation
Type: DC Axial Cooling Fan
Dimensions: 92mm x 92mm x 25mm
Rated Voltage: 24V DC
Rated Current: 0.26A
Rated Power: 6.24W
Speed: 3600 RPM
Airflow: 61.8 CFM / 1.75 m³/min
Static Pressure: 0.229 inch-H2O / 57.0 Pa
Noise Level: 44.5 dBA
Connector: 3-Wire Leads
Bearing Type: Ball Bearing
Life Expectancy: 50,000 hours at 25°C
Operating Temperature: -10°C to 70°C
Frame Material: Plastic
Impeller Material: Plastic
Features: Speed Sensor, Auto Restart, Polarity Protection
