Description
The ebmpapst 3956 is a 230VAC axial fan with dimensions of 92x92x25mm. Operating at both 50Hz and 60Hz frequencies, it draws 60mA of current and consumes 11W of power at 50Hz, and 50mA of current and 9W of power at 60Hz. This fan operates at speeds of 2650RPM at 50Hz and 3150RPM at 60Hz. Featuring durable ball bearings and 2 terminals, it is constructed with a metal housing and a mineral-reinforced PA plastic impeller, designed for reliable performance.
3956 Fan Parameters
Manufacturer: ebmpapst
Model: 3956
Fan Type: AC Axial Fan
Dimensions: 92 x 92 x 25 mm
Rated Voltage: 230 VAC
Frequency: 50 Hz / 60 Hz
Current Rating: 60 mA (50Hz), 50 mA (60Hz)
Power Consumption: 11 W (50Hz), 9 W (60Hz)
Speed: 2650 RPM (50Hz), 3150 RPM (60Hz)
Bearing Type: Ball Bearing
Termination: 2 Terminals
Housing Material: Metal
Impeller Material: Mineral-reinforced PA plastic
Weight: 0.28 kg
Approval Agency: VDE, CSA, UL, CE
Application: This ebmpapst AC axial fan is suitable for various cooling applications in electronic equipment, control cabinets, and general ventilation systems requiring compact and efficient air circulation.
Alternate Part Numbers：9282708100
