4312/19 ebmpapst DC12V 0.42A 5W axial fan

Description

The ebmpapst 4312/19 is a DC axial fan measuring 119x119x32mm. It operates on 12 VDC, drawing 0.42 A of current, with a power consumption of 5 W. This fan achieves a speed of 2800 RPM, providing an airflow of 2.8 m³/min (approximately 100 CFM). The noise level is 45 dB(A). It features ball bearings for reliable operation and connects via 3-wire Leads. The housing and impeller are made of glass-fiber reinforced plastic. This fan is commonly used in various electronic equipment, power supplies, and general cooling applications.

4312/19 Fan Parameters
Model: 4312/19
Manufacturer: ebmpapst
Type: DC Axial Fan
Dimensions: 119x119x32 mm
Rated Voltage: 12 VDC
Rated Current: 0.42 A
Nominal Voltage Range: 6 to 15 VDC
Power Consumption: 5 W
Speed: 2800 RPM
Airflow: 2.8 m³/min (100 CFM) / 170 m³/h
Noise Level: 45 dB(A)
Bearing Type: Ball Bearing
Termination: 3-wire Leads
Housing Material: Glass-fiber reinforced PBT plastic
Impeller Material: Glass-fiber reinforced PA plastic
Operating Temperature: -20 to 75°C
Expected Life: 62500 Hrs (at 40°C)
Application: Electronic equipment, power supplies, general cooling.
