4414F ebmpapst 24V DC Axial Fan

Description

The ebmpapst 4414F is a 24VDC axial fan with dimensions of 119x119x25mm. Operating within a 12-28VDC range, it draws 0.21A of current and consumes 5.0W of power. This fan delivers an airflow of 170m³/h (100CFM) and operates at a speed of 2900RPM, with a noise level of 43dB(A) and a sound power level of 5.3Bels. Featuring durable ball bearings and two wire leads for connection, it is constructed with a fiberglass-reinforced PBT plastic housing and a fiberglass-reinforced PA plastic impeller, boasting an IP20 ingress protection rating. It is suitable for reliable operation within an ambient temperature range of -20 to 60°C and has a typical service life of 60,000hours at 40°C.

4414F Fan Parameters
Manufacturer: ebmpapst
Model: 4414F
Fan Type: DC Axial Fan
Dimensions: 119 x 119 x 25 mm
Rated Voltage: 24 VDC
Operating Voltage Range: 12 ~ 28 VDC
Current Rating: 0.21 A
Power Consumption: 5.0 W
Airflow: 170 m³/h (100 CFM)
Speed: 2900 RPM
Noise Level: 43 dB(A)
Sound Power Level: 5.3 Bels
Bearing Type: Ball Bearing
Termination: Two Wire Leads
Operating Temperature: -20 ~ 60°C
Lifetime @ Temp: 60,000 Hours (at 40°C)
Housing Material: Plastic (Fiberglass-reinforced PBT plastic)
Impeller Material: Plastic (Fiberglass-reinforced PA plastic)
IP Rating: IP20
Weight: 0.175 kg
Approval Agency: CE, UL, CSA, VDE
Application: This ebmpapst DC axial fan is suitable for cooling electronic enclosures, compact systems, and other applications where efficient airflow and space-saving dimensions are key.
