4656NU ebmpapst 230V AC Axial Fan

Description

The ebmpapst 4656NU is a robust AC axial fan with dimensions of 119x119x38mm, designed for general cooling applications. Operating at 230VAC across 50Hz and 60Hz frequencies, it consumes 19W at 50Hz and 18W at 60Hz. This fan delivers a free-air flow of 110m³/h (50Hz) and 120m³/h (60Hz), with speeds of 2600RPM (50Hz) and 2950RPM (60Hz). Noise levels are 44dB(A) at 50Hz and 48dB(A) at 60Hz. It features durable ball bearings and is terminated via terminals for reliable connection. Built with a metal housing and a metal impeller, it boasts an IP54 ingress protection rating, ensuring dependable performance within an ambient temperature range of -40 to 85°C. It is certified by CE, EAC, UL, VDE, CSA, and CCC.

4656NU Fan Parameters
Manufacturer: ebmpapst
Model: 4656NU
Fan Type: AC Axial Fan
Dimensions: 119 x 119 x 38 mm
Rated Voltage: 230 VAC
Frequency: 50 Hz / 60 Hz
Power Consumption: 19 W (50Hz), 18 W (60Hz)
Airflow: 110 m³/h (50Hz), 120 m³/h (60Hz)
Speed: 2600 RPM (50Hz), 2950 RPM (60Hz)
Noise Level: 44 dB(A) (50Hz), 48 dB(A) (60Hz)
Bearing Type: Ball Bearing
Termination: Terminals
Operating Temperature: -40 ~ 85°C
Frame Material: Metal
Blade Material: Metal
IP Rating: IP54
Weight: 0.55 kg
Approval Agency: CE, EAC, UL, VDE, CSA, CCC
Application: This ebmpapst AC axial fan is suitable for various cooling and ventilation applications in industrial equipment, control cabinets, and HVAC systems requiring a robust and protected fan.
