Description
Model Number: 4715KL-05W-B30
Manufacturer: NMB Technologies Corporation
Series: 4715KL
Fan Type: DC Brushless Axial Fan
Dimensions L x H x W: 120 mm x 120 mm x 38 mm
Rated Voltage: 24 VDC
Operating Voltage Range: 10 VDC to 27.6 VDC
Rated Current: 0.31 A
Input Power: 7.44 W
Wiring: 2 Wire Leads
Bearing Type: Ball Bearing
Rotational Speed RPM: 2950 RPM
Maximum Airflow: 108 CFM
Maximum Static Pressure: 0.27 in H2O
Noise Level: 42.5 dB
Frame Material: Plastic
Impeller Blade Material: Plastic
Protection Functions: Auto Restart, Polarity Protection
Operating Temperature Range: -10°C to +70°C
Expected Life L10: 50,000 Hours at 25°C
Mass: 260 g
The NMB 4715KL-05W-B30 is a highly reliable 120x120x38mm DC axial fan from NMB Technologies, designed for effective cooling in a wide range of electronic and industrial applications. Operating on 24VDC, it typically consumes 7.44W of power with a current draw of 0.31A. This fan features durable ball bearings for a long expected life of 50,000 hours. It delivers a substantial airflow of 108 CFM at 2950 RPM, with a moderate noise level of 42.5 dB. Constructed from plastic, it includes essential protection features like auto restart and polarity protection, making it a robust and efficient solution for servers, power supplies, control panels, and other equipment requiring continuous and dependable DC cooling.
