712F ebmpapst 12V DC Axial Fan

Description

The ebmpapst 712F is a 12VDC axial fan with dimensions of 70x70x15mm. Operating within an 8-13.8VDC range, it draws 0.14A of current and consumes 1.7W of power. This fan delivers an airflow of 44m³/h (26CFM) and operates at a speed of 5300RPM, with a noise level of 38dB(A) and a sound power level of 5.3Bels. Featuring durable ball bearings and two wire leads for connection, it is constructed with a fiberglass-reinforced PBT plastic housing and a fiberglass-reinforced PA plastic impeller, boasting an IP20 ingress protection rating. It is suitable for reliable operation within an ambient temperature range of -20 to 70°C and has a typical service life of 60,000hours at 40°C.

712F Fan Parameters
Manufacturer: ebmpapst
Model: 712F
Fan Type: DC Axial Fan
Dimensions: 70 x 70 x 15 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 8 ~ 13.8 VDC
Current Rating: 0.14 A
Power Consumption: 1.7 W
Airflow: 44 m³/h (26 CFM)
Speed: 5300 RPM
Noise Level: 38 dB(A)
Sound Power Level: 5.3 Bels
Bearing Type: Ball Bearing
Termination: Two Wire Leads
Operating Temperature: -20 ~ 70°C
Lifetime @ Temp: 60,000 Hours (at 40°C)
Housing Material: Plastic (Fiberglass-reinforced PBT plastic)
Impeller Material: Plastic (Fiberglass-reinforced PA plastic)
IP Rating: IP20
Weight: 0.053 kg
Approval Agency: VDE, CSA, UL, CE
Application: This ebmpapst DC axial fan is suitable for cooling small electronic devices, compact enclosures, and various systems where efficient airflow is crucial within space-constrained applications.
