Description
The Sanyo Denki 9A0912L401, part of the San Cooler 92 Series, is a compact and quiet 12V DC axial cooling fan, measuring 92x92x25mm. It operates with a rated current of 0.070A (0.84W). This fan delivers 28.2 CFM of airflow at 1750 RPM, with a minimal noise level of 23.0 dBA, making it ideal for applications where low noise and efficient cooling are important.
Equipped with durable ball bearings, it boasts a long operational life of 40,000 hours at 60°C. The 3-wire configuration includes a speed sensor (tachometer output) and locked rotor protection, offering reliable monitoring and enhanced system protection. This fan is a great choice for various electronic devices, PCs, and smaller enclosures requiring reliable and quiet thermal management.
Model Number: 9A0912L401
Manufacturer: Sanyo Denki
Series: San Cooler 92
Type: DC Axial Cooling Fan
Dimensions: 92mm x 92mm x 25mm
Rated Voltage: 12V DC
Operating Voltage Range: 7V to 13.8V DC
Rated Current: 0.070A
Rated Power: 0.84W
Speed: 1750 RPM
Airflow: 28.2 CFM / 0.790 m³/min
Static Pressure: 0.054 inch-H2O / 13.4 Pa
Noise Level: 23.0 dBA
Connector: 3-Wire Leads
Bearing Type: Ball Bearing
Life Expectancy (L10): 40,000 hours at 60°C
Operating Temperature: -20°C to 70°C
Frame Material: Plastic
Impeller Material: Plastic
Features: Locked Rotor Protection, Speed Sensor (Tachometer Output), Auto Restart, Reverse Polarity Protection
