9AH0912M403 Sanyo Denki 12V 0.08A 92mm 9225 DC Axial Fan

Description

The Sanyo Denki 9AH0912M403 is a high-performance 12 V industrial axial fan with dimensions of 92 x 92 x 25 mm, purpose-built to deliver elite-level thermal cooling in high-resistance airflow paths. This unit features a heavy-duty brushless DC motor capable of sustaining a 0.96 W power input to drive its specialized 7-blade impeller at a consistent 2500 RPM. Engineered specifically for air displacement in standard-profile enclosures, it utilizes a 25 mm housing to provide balanced pressure and airflow for mission-critical hardware. The mechanical design relies on precision dual ball bearings and a fiberglass-reinforced PBT housing to ensure 40,000 hours of continuous operation at a 60 °C ambient temperature. Featuring a robust 3-wire electrical interface with a dedicated Tachometer (FG) output for real-time speed monitoring, this fan is a critical component for server racks, power supply cooling, and industrial automation where long-term reliability and precise system feedback are mandatory.

9AH0912M403 Fan Parameters
Manufacturer: Sanyo Denki (San Ace 92)
Model Number: 9AH0912M403
Series: 9AH Series (High Static Pressure Type)
Industry Size Code: 9225
Type: DC Axial Fan
Bearing Type: Dual Ball Bearing
Nominal Voltage: 12 VDC
Voltage Range: 10.2 – 13.8 VDC
Starting Voltage: 7 VDC
Dimensions: 92 x 92 x 25 mm
Weight: 110 g

[Electrical Data]
Input Power: 0.96 W
Nominal Current: 0.08 A
Max. Current: 0.12 A (Peak startup current)
Nominal Speed: 2500 RPM (Tolerance ±10%)
Motor Design: Brushless DC Motor (4-pole)
Signal Output: FG (Frequency Generator / Tachometer)
Motor Protection: Locked Rotor Protection, Reverse Polarity Protection
Insulation Class: Class E
Insulation Resistance: >10M ohm at 500 VDC
Dielectric Strength: 500 VAC for 1 minute
Termination: 3-Lead wires (UL1007, AWG 24, Red/Black/Yellow)

[Performance & Acoustics]
Max. Air Flow: 41.3 CFM (70.2 m³/h / 1.17 m³/min)
Max. Static Pressure: 3.47 mmH₂O (34.0 Pa / 0.14 inH₂O)
Sound Pressure Level: 28 dB(A) (Measured at 1 m)
Number of Blades: 7
Direction of Rotation: Clockwise (Viewed toward rotor)
Airflow Direction: Intake over struts (Exhaust toward label)
Mode of Operation: S1 (Continuous operation)

[Materials & Construction]
Frame Material: Plastic (PBT reinforced with 30% glass fiber, UL94V-0)
Impeller Material: Plastic (PBT reinforced with 15% glass fiber, UL94V-0)
Installation Position: Any
Degree of Protection: IP20

[Reliability & Safety Standards]
Min. Ambient Temperature: -20 °C
Max. Ambient Temperature: 70 °C
Storage Temperature: -30 °C – 70 °C
Life Expectancy (L10): 40,000 hours at 60 °C (70,000 hours at 40 °C)
Standard Compliance: UL 507, CSA C22.2, EN 60950-1, RoHS
Approval Agency: UL, CUL, TUV, CE

Application
The Sanyo Denki 9AH0912M403 axial fan is used in industrial server chassis, telecommunications base stations, power supply units, medical laboratory equipment, and automated control cabinets.
