Description
Model Number: 9GT0424P3J001
Manufacturer: Sanyo Denki
Series: San Ace 40T (Wide Temperature Range Fan)
Fan Type: DC Brushless Axial Fan (Tubeaxial)
Dimensions (L x H x W): 40 mm x 40 mm x 28 mm
Rated Voltage: 24 VDC
Operating Voltage Range: 20.4 VDC to 27.6 VDC
Rated Current: 0.150 A
Input Power: 3.6 W
Wiring: 4 Lead Wires (includes Positive, Negative, Pulse Sensor Output, and PWM Control Input)
Protection Functions: Locked Rotor Burnout Protection, Reverse Polarity Protection
Rotational Speed (RPM): 11700 RPM
Maximum Airflow:
18.4 CFM (Cubic Feet per Minute)
0.52 m³/min (Cubic Meters per Minute)
31.2 m³/h (Cubic Meters per Hour)
Maximum Static Pressure:
0.827 in H2O (Inches of Water)
206 Pa (Pascals)
Noise Level: 48.0 dB(A)
Bearing Type: Ball Bearing
Frame Material: Aluminum (Black coating, as per some datasheets) / Plastic (UL 94V-0 Flame Retardancy, general for San Ace fans) – Note: Some sources specify Aluminum frame for this model, while others state general plastic. Aluminum is more typical for high-performance/wide-temp fans.
Impeller (Blade) Material: Plastic (UL 94V-1 Flame Retardancy)
Frame Design: Ribless (some sources specify “Ribbed No”)
Sensor Type: Pulse Sensor (Tachometer output for speed monitoring)
Control Function: PWM Control (Pulse Width Modulation for speed regulation)
Operating Temperature Range: -40°C to +85°C
Expected Life (L10): 40,000 hours at 85°C (or 162,000 hours at 40°C)
Safety Approvals: CSA, TUV, UL
Mass: Approximately 55 g
The Sanyo Denki 9GT0424P3J001 is a high-performance, compact 40x40x28mm DC axial fan from the San Ace 40T “Wide Temperature Range” series. It operates on 24VDC with 0.150A current and 3.6W power, capable of delivering a high 18.4 CFM (0.52 m³/min) of airflow and significant 0.827 in H2O (206 Pa) static pressure at a fast 11700 RPM, with a noise level of 48.0 dB(A). Featuring durable ball bearings and a robust design (likely aluminum frame), it supports a very wide operating temperature range from -40°C to +85°C. Equipped with both a pulse sensor for speed monitoring and PWM control for precise speed regulation, along with locked rotor and reverse polarity protection, this fan offers a long L10 life of 40,000 hours at 85°C, making it ideal for demanding environments where consistent performance and reliability are critical.
