Description
The ADDA AB7012HB-E01 is a compact DC blower measuring 70 x 70 x 12 mm. It operates on 12V DC, drawing 0.18 A of current and consuming 2.16 W of power. The blower delivers a focused airflow of 6.58 CFM and a high static pressure of 0.320 inch H₂O. It runs at a speed of 3800 RPM with a low noise level of 33.4 dB(A). This blower uses ball bearings for enhanced durability and weighs 135 g with two-wire leads. This blower is ideal for cooling components in confined spaces.
AB7012HB-E01 Fan Parameters
Manufacturer: ADDA
Model: AB7012HB-E01
Fan Type: DC Blower
Dimensions: 70 x 70 x 12 mm
Rated Voltage: 12V DC
Current Rating: 0.18 A
Power Consumption: 2.16 W
Airflow: 6.58 CFM
Static Pressure: 0.320 inch H₂O
Speed: 3800 RPM
Noise Level: 33.4 dB(A)
Bearing Type: Ball Bearing
Weight: 135 g
Termination: Two Wire Leads
Application: The ADDA AB7012HB-E01 is a high-static pressure fan designed for targeted cooling in applications with restricted airflow. Its compact size and blower design make it suitable for cooling CPUs and GPUs in small form-factor PCs, projectors, telecommunications equipment, and other electronic devices where space is limited and powerful, directed airflow is necessary.
