Description
The ADDA AD0405LX-K90 is a high-performance DC Axial Fan with dimensions of 40 x 40 x 7 mm. It operates on a nominal voltage of 5 VDC. The fan achieves a speed of 4500 RPM, consuming 0.25 W of power and drawing a maximum current of 0.05 A. It delivers a maximum air flow of 6.42 m³/h (3.78 CFM) and a maximum static pressure of 10.0 Pa (0.04 inAq). This 9-blade fan utilizes an ultra-quiet Sleeve Bearing system and is ideal for cooling compact electronic devices, embedded systems, and mini PCs with extremely limited vertical space.
AD0405LX-K90 Fan Parameters
Model: AD0405LX-K90
Manufacturer: ADDA
Type: MINI DC Axial Fan
Dimensions (measuring): 40 x 40 x 7 mm
Nominal Voltage: 5 VDC
Voltage Range: 4.5 VDC ~ 5.5 VDC
Speed: 4500 RPM
Power Consumption: 0.25 W
Current Draw: 0.05 A
Max. Airflow: 6.42 m³/h (3.78 CFM)
Max. Static Pressure: 10.0 Pa (0.04 inAq)
Noise Level: 19.5 dB(A)
Weight: 0.015 kg
Housing Material: Thermoplastic PBT (UL94V-0)
Impeller Material: Thermoplastic PBT (UL94V-0)
Number of Blades: 9
Bearing Type: Sleeve Bearing
Motor Design: Brushless DC Motor
Motor Protection: Locked Rotor Protection
Termination: 2 Wire Leads
Monitor Output: No
Service Life L10 at 40 °C: 30000 h
Min. Ambient Temperature: -10 °C
Max. Ambient Temperature: 70 °C
Approvals: UL, CE
Application
The ADDA AD0405LX-K90 fan is designed for compact, low-power applications requiring a super-slim profile and exceptionally quiet operation. Primary applications for the AD0405LX-K90 include cooling thin-profile single-board computers, portable electronic devices, ultra-slim hard drive enclosures, and miniature network components where minimal acoustic footprint and restricted space are paramount.
