Description
The ADDA AD0412UB-C50 is a high-performance DC Axial Fan with dimensions of 40×40×20 mm. This ultra-high speed (U) fan operates on a nominal 12 VDC voltage and utilizes a Ball Bearing system. It has a power consumption of 1.68 W and achieves a high speed of 8,500 RPM. It delivers a strong airflow of 18.0 m3/h (10.6 CFM) and a high static pressure of 80.9 Pa (0.325 inH2O). The noise level is 36.1 dB(A).
AD0412UB-C50 Fan Parameters
Model: AD0412UB-C50
Manufacturer: ADDA
Fan Type: DC Axial Fan
Dimensions: 40×40×20 mm
Nominal Voltage: 12 VDC
Rated Current: 0.14 A
Rated Power: 1.68 W
Rated Speed: 8,500 RPM
Airflow: 18.0 m3/h (10.6 CFM)
Static Pressure: 80.9 Pa (0.325 inH2O)
Noise Level: 36.1 dB(A)
Bearing System: Ball Bearing
Motor Design: Brushless DC Motor
Number of blades: 5
Frame Material: Plastic (UL94V-0)
Impeller Material: Plastic (UL94V-0)
Termination: 2-Wire Leads
Application
The AD0412UB-C50 is a compact, high-speed fan designed for critical spot cooling and exhausting warm air in space-constrained electronic devices. Its high static pressure capability makes it excellent for overcoming resistance in high-performance embedded systems, network routers, small form-factor PCs, and industrial control panels where component density is very high.
