Description
The ADDA AD0612DB-D72GL is a high-efficiency DC axial fan, commonly referred to as a “6015” size, designed for precision thermal management in space-constrained electronic environments. This 60 x 60 x 15 mm unit features ADDA’s proprietary Hypro Bearing system, which offers a silent operational profile and an extended service life. Operating at 12 VDC with a low-power current draw of 0.07 A, it delivers a nominal speed of 3500 RPM. The 3-wire configuration includes a dedicated Tachometer (FG) signal for real-time monitoring of the fan’s rotation. Built with a brushless DC motor and a reinforced 7-blade impeller, this fan provides a balanced airflow of 14.348 CFM with a significantly reduced acoustic signature of 27.4 dB(A), making it an ideal cooling solution for noise-sensitive applications such as network switches, DVRs, and medical instrumentation.
AD0612DB-D72GL Fan Parameters
Manufacturer: ADDA
Model Number: AD0612DB-D72GL
Industry Size Code: 6015
Type: DC axial fan
Bearing Type: Hypro Bearing
Nominal Voltage: 12 VDC
Voltage Range: 10.8 – 13.2 VDC
Starting Voltage: 9.0 VDC
Dimensions: 60 x 60 x 15 mm
[Electrical Data]
Input Power: 0.84 W
Nominal Current: 0.07 A
Max. Current: 0.09 A
Nominal Speed: 3500 RPM (Tolerance ±10%)
Motor Design: Brushless DC Motor, 4-pole
Signal Output: FG (Frequency Generator/Tachometer)
Motor Protection: Auto Restart, Polarity Protection, Locked Rotor Protection
Insulation Resistance: 10M ohm at 500 VDC
Termination: 3-Lead wires (UL1007, AWG#26, Red/Black/White)
[Performance & Acoustics]
Max. Air Flow: 14.348 CFM (24.38 m³/h / 0.41 m³/min)
Max. Static Pressure: 4.83 mmH₂O (47.37 Pa / 0.19 inH₂O)
Sound Pressure Level: 27.4 dB(A)
Number of Blades: 7
Direction of Rotation: Counter-clockwise (viewed toward impeller)
Airflow Direction: Intake over struts
[Materials & Construction]
Frame Material: Thermoplastic PBT (UL94V-0)
Impeller Material: Thermoplastic PBT (UL94V-0)
Installation Position: Any
Degree of Protection: IP54
[Reliability & Safety Standards]
Min. Ambient Temperature: -10 °C
Max. Ambient Temperature: 70 °C
Life Expectancy (L10): 50,000 hours at 40 °C
Standard Compliance: IEC 60950-1, EN 61000-6-1/3
Approval Agency: UL, TUV, CE, RoHS
Application
The ADDA AD0612DB-D72GL axial fan is used in network routers, compact power supplies, industrial control workstations, micro-servers, medical monitoring equipment, and security DVR systems.
