Description
The ADDA AD0612UB-F73DS is a high-performance DC Axial Fan with dimensions of 60 mm x 60 mm x 38 mm. Operating on 12 VDC within a range of 10.8 VDC to 13.2 VDC, this fan is an Ultra-High Speed model achieving 10000 RPM (± 10%). Its actual power consumption is 16.80 W (1.40 A), while the maximum rated power is 21.60 W (1.80 A). It delivers a high airflow of 99.6 m³/h (58.665 CFM) and an exceptional static pressure of 1.471 inAq (37.363 mm H2O), with a noise level of 64.7 dB(A). Built with Dual Ball Bearings, it features integrated IC-based motor and polarity protection, and boasts a long life expectancy of 70000 hours at 40 °C.
AD0612UB-F73DS Fan Parameters
Model: AD0612UB-F73DS
Manufacturer: ADDA
Type: DC Axial Fan
Dimensions: 60 mm x 60 mm x 38 mm
Motor Design: Brushless DC Motor
Nominal Voltage: 12.0 VDC
Operating Voltage Range: 10.8 VDC to 13.2 VDC
Start-Up Voltage: 9.0 VDC
Rated Current: 1.80 A
Actual Current: 1.40 A
Rated Power: 21.60 W
Actual Power: 16.80 W
Speed: 10000 RPM (± 10 %)
Airflow: 99.6 m³/h (58.665 CFM)
Static Pressure: 1.471 inAq (37.363 mm H2O)
Noise: 64.7 dB(A)
Bearing Type: Ball Bearing
Features: Motor Protection (By IC) / Polarity Protection (Yes)
Termination Style: Wire Leads
Frame Material: Plastic (UL94V-0)
Impeller Material: Plastic (UL94V-0)
Safety Approval: UL, CUL, TUV, CE
Life Expectancy: 70000 hours at 40 °C / 65% RH
Weight: 109 g
ApplicationThe ADDA AD0612UB-F73DS is a heavy-duty, ultra-high performance fan designed for mission-critical applications where maximum heat dissipation and sustained operation are non-negotiable. Its high static pressure capability is perfect for overcoming significant back pressure in dense electronic assemblies like high-end rack servers, industrial computers, communication routers, and cooling systems with restrictive air filters or heat sinks. The robust Two Ball Bearing system and long life expectancy are tailored for continuous 24/7 industrial use.
Suggested Retail Price: $22.99$
