AD0812MX-A76GL ADDA 12V DC Axial Fan

$12.97

SKU: AD0812MX-A76GL
Tag:

Description

The ADDA AD0812MX-A76GL is a high-performance DC Axial Fan with dimensions of 80×80×25 mm. This model operates on 12 VDC, delivering an airflow of approximately 53.4 m3/h (31.4 CFM) and a static pressure of approximately 28.4 Pa (0.114 inH2O) at a speed of 2,440 RPM. It features a HYPRO Bearing system, a low noise level of 28.3 dB(A), a rated power of 1.8 W, and holds multiple safety approvals including UL,CUL,TUV,CSA, and CE.

AD0812MX-A76GL Fan Parameters
Model: AD0812MX-A76GL
Manufacturer: ADDA
Fan Type: DC Axial Fan
Dimensions: 80×80×25 mm
Nominal Voltage: 12 VDC
Rated Current: 0.15 A
Rated Power: 1.8 W
Rated Speed: 2,440 RPM
Airflow: 53.4 m3/h (31.4 CFM)
Static Pressure: 28.4 Pa (0.114 inH2O)
Noise Level: 28.3 dB(A)
Bearing System: HYPRO Bearing
Termination: 3-Wire Leads
Number of blades: 7
Frame Material: Plastic (UL94V-0)
Impeller Material: Plastic (UL94V-0)
Weight: 86 g
Approvals: UL,CUL,TUV,CSA,CE

Application
The AD0812MX-A76GL is typically used in applications requiring reliable cooling with a low noise profile within the 80 mm size, such as desktop personal computers, audio/visual equipment, set-top boxes, small instrumentation, and light-duty industrial equipment.

AD0812MX-A76GL ADDA 12V DC Axial Fan
AD0812MX-A76GL ADDA 12V DC Axial Fan
AD0812MX-A76GL ADDA 12V DC Axial Fan
AD0812MX-A76GL ADDA 12V DC Axial Fan

Additional information

Weight 0.5 kg
