AD1248HX-F52 ADDA 48V DC Axial Fan 120mm

Description

The ADDA AD1248HX-F52 is a high-performance DC Axial Fan with dimensions of 120 x 120 x 38 mm. It operates on a nominal voltage of 48 VDC. The fan achieves a speed of 2800 RPM, consuming 9.6 W of power and drawing a maximum current of 0.20 A. It delivers a maximum air flow of 178.0 m³/h (104.8 CFM) and a maximum static pressure of 67.2 Pa (0.270 inAq). This 5-blade fan utilizes a HYPRO Bearing system and features four-wire termination for speed control and monitoring, making it ideal for standard 48V cooling applications.

AD1248HX-F52 Fan Parameters
Model: AD1248HX-F52
Manufacturer: ADDA
Type: DC Axial Fan
Dimensions (measuring): 120 x 120 x 38 mm
Nominal Voltage: 48 VDC
Voltage Range: 28 VDC ~ 53 VDC
Speed: 2800 RPM
Power Consumption: 9.6 W
Current Draw: 0.20 A
Max. Airflow: 178.0 m³/h (104.8 CFM)
Max. Static Pressure: 67.2 Pa (0.270 inAq)
Noise Level: 42.8 dB(A)
Weight: 0.297 kg
Housing Material: Thermoplastic PBT (UL94V-0)
Impeller Material: Thermoplastic PBT (UL94V-0)
Number of Blades: 5
Bearing Type: HYPRO Bearing
Motor Design: Brushless DC Motor
Motor Protection: Locked Rotor Protection, Auto-Restart
Termination: 4 Wire Leads
Monitor Output: Yes (Tachometer/FG and PWM)
Service Life L10 at 40 °C: 50000 h
Min. Ambient Temperature: -10 °C
Max. Ambient Temperature: 70 °C
Approvals: UL, CUL, CSA, CE

Application
The ADDA AD1248HX-F52 fan is designed for quiet and efficient cooling in 48V telecommunication, industrial, and server systems that require precise speed control and monitoring. Primary applications include cooling network infrastructure, data storage arrays, and electronic enclosures where airflow and acoustic optimization is necessary.
