AFB1212LE-02 Delta 12V 0.24A DC axial fan

Description

The Delta AFB1212LE-02 is a 12V DC axial cooling fan. Measuring 120mm x 120mm x 38mm, this fan is designed for efficient general-purpose cooling. It operates at a rated voltage of 12V DC, drawing 0.24A of current for a power consumption of 2.88W. It delivers an airflow of 84.76 CFM (2.400 m³/min) at a speed of 2000 RPM, with a relatively low noise level of 34.0 dBA. This fan features a durable ball bearing system and typically connects via 2-wire leads. Its robust construction includes a plastic frame and impeller, and it is designed for a long operational life.

Model Number: AFB1212LE-02
Manufacturer: Delta Electronics
Type: DC Axial Cooling Fan
Dimensions: 120mm x 120mm x 38mm
Rated Voltage: 12V DC
Operating Voltage Range: 4V to 13.2V DC
Rated Current: 0.24A
Rated Power: 2.88W
Speed: 2000 RPM
Airflow: 84.76 CFM (2.400 m³/min)
Static Pressure: 0.180 inch-H2O (4.56 mmH2O)
Noise Level: 34.0 dBA
Connector: 2-Wire Leads
Bearing Type: Ball Bearing
Frame Material: Plastic
Impeller Material: Plastic
Operating Temperature: -10°C to +60°C
Weight: 256g
Features: Locked Rotor Protection
Life Expectancy: 70,000 Hours @ 40°C
Approvals/Certifications: CE, CSA, UL, VDE

Tip: The refrigerator connector is sent by default, see the last picture
