Description
The ADDA AQ0824UB-A71GL is a DC axial fan designed for high-performance cooling, featuring dimensions of 80 x 80 x 25 mm. It operates on 24V DC, with a current draw of 0.26 A and a power consumption of 6.24 W. This fan runs at a speed of 3900 RPM, delivering an airflow of 50 CFM with a static pressure of 0.279 inch H₂O. The noise level is 41 dB(A). It utilizes a reliable ball bearing system and is equipped with two-wire leads. The housing and impeller are constructed from UL94V-0 glass-filled polyester (P.B.T), and it has a rated life expectancy of 70,000 hours at 40°C / 65%. The fan operates effectively within a temperature range of -10 °C to 70 °C.
AQ0824UB-A71GL Fan Parameters
Manufacturer: ADDA
Model: AQ0824UB-A71GL
Fan Type: DC Axial Fan
Dimensions: 80 x 80 x 25 mm
Rated Voltage: 24V DC
Current Rating: 0.26 A
Power Consumption: 6.24 W
Airflow: 50 CFM
Static Pressure: 0.279 inch H₂O
Speed: 3900 RPM
Noise Level: 41 dB(A)
Bearing Type: Ball Bearing
Termination: 2-Wire Leads
Housing Material: UL94V-0 Glass Filled polyester (P.B.T)
Impeller Material: UL94V-0 Glass Filled polyester (P.B.T)
Operating Temperature: -10 °C to 70 °C
Life Expectancy: 70,000 Hours at 40 °C / 65%
Application
The AQ0824UB-A71GL fan is suitable for demanding cooling applications that require high airflow and static pressure, such as in industrial automation equipment, servers, telecommunications devices, and high-performance computing systems.
