DV6224 ebmpapst 24V DC Axial Fan

Description

The ebmpapst DV6224 is a 24VDC axial fan, measuring 172x150x51mm. Operating within a 16-28V range, it draws 1.54A of current and consumes 37W of power. This fan operates at a high speed of 4300RPM, with a noise level of 63dB(A). Featuring durable ball bearings and 2 wire leads, it’s built with a plastic frame and impeller, ensuring reliable performance within an ambient temperature range of -20 to 75°C.

DV6224 Fan Parameters
Manufacturer: ebmpapst
Model: DV6224
Fan Type: DC Axial Fan
Dimensions: 172 x 150 x 51 mm
Rated Voltage: 24 VDC
Operating Voltage Range: 16 ~ 28 VDC
Current Rating: 1.54 A
Power Consumption: 37 W
Speed: 4300 RPM
Noise Level: 63 dB(A)
Bearing Type: Ball Bearing
Termination: 2 Wire Leads
Operating Temperature: -20 ~ 75°C
Lifetime @ Temp: 50,000 Hours (at 40°C)
Frame Material: Plastic
Blade Material: Plastic
Weight: 0.82 kg
Approval Agency: VDE, CSA, UL, CE
Application: This ebmpapst DC axial fan is suitable for cooling applications in servers, telecommunications equipment, power supplies, and industrial machinery where powerful and efficient airflow is required.
