Description
The SUNON EF80251S1-1000C-A99 is a DC axial fan measuring 80x80x25mm. It operates on 12 VDC, drawing 0.138 A of current, with a power consumption of 1.66 W. This fan achieves a speed of 3200 RPM, providing an airflow of 41 CFM (approximately 69.29 m³/h). The noise level is 33 dB(A). It features a sleeve bearing for smooth operation and connects via 2 wire leads. The frame and impeller are made of thermoplastic (PBT), with a UL94V-0 flammability rating. It includes an auto-restart function for motor protection. This fan is commonly used in various electronic equipment, servers, and general cooling applications where efficient and durable airflow is required.
EF80251S1-1000C-A99 Fan Parameters
Model: EF80251S1-1000C-A99
Manufacturer: SUNON
Type: DC Axial Fan
Dimensions: 80x80x25 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 4.5 to 13.8 VDC
Rated Current: 0.138 A
Power Consumption: 1.66 W
Speed: 3200 RPM
Speed Tolerance: ±10%
Airflow: 41 CFM (69.29 m³/h)
Static Pressure: 0.180 inH2O (44.8 Pa)
Noise Level: 33 dB(A)
Bearing Type: Sleeve Bearing
Termination: 2 Wire Leads
Frame Material: Thermoplastic (PBT)
Impeller Material: Thermoplastic (PBT)
Flammability Rating: UL94V-0
Operating Temperature: -10 to 70°C
Expected Life: 70,000 hours (at 40°C, 65% humidity)
Motor Protection: Auto Restart
Weight: 75.75 g
Application: Electronic equipment, servers, general cooling.
