Description
Manufacturer: ZIEHL-ABEGG
Model: FN063-6EK.4I.V7P1
Product Type: Axial Fan
Motor Technology: AC External Rotor Motor
Impeller Diameter: 630 mm
Number of Blades: 6 Sickle blades
Bearing Type: Ball Bearing, with long-time lubrication
Protection Class: IP54
Thermal Class: THCL155
Electrical Connection: Terminal box K62
Design: K
Airflow Direction: V Ventilating, air blows over the motor side
Weight: Approximately 15.4 kg slight variations between sources
Minimum Operating Temperature: -25 °C
Maximum Medium Temperature: 70 °C
Conformity: ErP 2015, CE
Parameters at 50Hz Operation 1~ 230V ±10%:
Frequency: 50 Hz
Rated Power Input P1: Approximately 660 W – 760 W slight variations between sources
Rated Current IN: Approximately 3.0 A – 3.7 A slight variations between sources
Rated Speed nN: Approximately 860 RPM – 870 RPM
Service Capacitor: 12 µF / 400V
Airflow: Approximately 10100 m³/h – 12547 m³/h significant variation between sources, depends on static pressure operating point
Noise: Approximately 66 dB – 74 dB(A) significant variation between sources, different measurement standards or operating points, refer to the official performance curve diagram for detailed values
