Description
The Jiulong G9025HA2BL is a standard 92x92x25mm AC axial fan designed for cooling various electronic components and industrial equipment. It operates on 220 VAC at 50/60 Hz, drawing 0.07A of current and consuming 13W of power. This fan typically provides an airflow between 23 to 37 CFM and operates with a noise level in the range of 23 to 40 dB(A). It utilizes ball bearings for reliable performance and often features an aluminum alloy frame with PBT thermoplastic impeller blades, making it suitable for server cooling, power supplies, and control cabinets.
G9025HA2BL Fan Parameters
Model: G9025HA2BL
Manufacturer: Jiulong
Type: AC Axial Fan
Dimensions: 92mm x 92mm x 25mm
Rated Voltage: 220 VAC
Frequency: 50 Hz / 60 Hz
Rated Current: 0.07A
Power Consumption: 13 W
Speed: 2350 RPM (50Hz) / 2800 RPM (60Hz)
Airflow: 23 CFM (50Hz) / 37 CFM (60Hz)
Noise Level: 34 dB(A) (50Hz) / 40 dB(A) (60Hz)
Bearing Type: Ball Bearing
Frame Material: Aluminum Alloy
Impeller Material: PBT Thermoplastic
Termination: 2-Wire Leads
Application: Server cooling, power supplies, control cabinets, electronic enclosures, general equipment ventilation.
