Jiulong 145FZY6-S 380V dual ball axial flow fan

Description

【Original】Jiulong 145FZY6-S 380V 172*150*38MM dual ball axial flow fan
Jiulong 145FZY6-S 380V dual ball axial flow fan
Model Number: 145FZY6-S
Fan Type: AC Axial Flow Fan
Dimensions L x H x W: 172 mm x 150 mm x 40 mm
Rated Voltage: 380 VAC
Frequency: 50 Hz
Phase: Single-phase
Rated Current: 0.15 A
Input Power: 30 W
Wiring: 2-Wire
Bearing Type: Ball Bearing
Rotational Speed RPM: 2600 RPM
Maximum Airflow: 4.87 m³/min
Noise Level: 57 dB
Frame Material: Metal
Impeller Blade Material: Not consistently specified, but typically plastic or metal
Weight: 740 grams
The 145FZY6-S is a robust 172x150x40mm AC axial fan designed for industrial cooling applications. Operating on 380 VAC single-phase power at 50Hz, it consumes 30W with a 0.15A current draw. This fan features ball bearings for durability and delivers 4.87 m³/min of airflow at 2600 RPM, with a noise level of 57 dB. It is built with a metal frame and is commonly used in various industrial equipment, including welding machines, for reliable thermal management.
