Description
The Sunon MB40201VX-0000-G99 is a compact yet powerful 12V DC axial fan measuring 40x40x20mm. It features Sunon’s proprietary Vapo-Bearing™ (MagLev) technology, which provides exceptional reliability, extended operational life of 70,000 hours, and enhanced resistance to dust and oil leakage. This fan delivers a robust 18.35 m³/h (10.8 CFM) of airflow at a high speed of 8200 RPM, coupled with a low noise level of 27.5 dBA. Its balanced performance makes it an excellent choice for cooling densely packed electronic components in applications like mini PCs, CPU coolers, networking devices, and other embedded systems where space is at a premium and reliable, quiet cooling is essential.Brand new original SUNON built-in MB40201VX-0000-G99 12V 1.38W 4020 silent fan
Manufacturer: Sunon
Model: MB40201VX-0000-G99
Type: DC Axial Fan
Dimensions: 40mm x 40mm x 20mm
Nominal Voltage: 12V DC
Current: 0.115A
Power Consumption: 1.38W
Speed: 8200 RPM
Airflow: 18.35 m³/h (or 10.8 CFM)
Static Pressure: 6.86 mm H2O (or 0.270 In H2O)
Noise Level: 27.5 dBA
Bearing Type: Vapo-Bearing™
Termination: 3-wire leads
Life Expectancy: 70,000 hours at 40°C
Frame and Blade Material: Thermoplastic PBT (UL94V-0 flame rating)
Features: Auto-Restart, brushless DC motor, good dust resistance, oil leak prevention
Safety Approvals: CE, cURus, TUV, UL
