Description
The SUNON PF60251BX-Q070-S99 is a powerful 12V DC axial cooling fan, measuring 60mm x 60mm x 25mm. Operating at a rated power of 3.78W, it draws a current of 0.315A. This fan is engineered for demanding thermal management in applications such as servers, networking equipment, and various industrial electronics that require significant airflow within a confined space. It achieves a high rotational speed of 8300 RPM, delivering a robust 40.0 CFM of airflow with a static pressure of 0.660 inch-H2O (164.4 Pa). The noise level is 46.0 dBA. Equipped with ball bearings (often Sunon’s advanced Vapo bearing system), it offers a long operational life. The fan typically utilizes a 4-wire connector to support PWM (Pulse Width Modulation) for precise speed control and includes a speed sensor (tachometer) output, ensuring reliable performance and control in critical cooling scenarios.
Model Number: PF60251BX-Q070-S99
Manufacturer: SUNON
Type: DC Axial Cooling Fan
Dimensions: 60mm x 60mm x 25mm
Rated Voltage: 12V DC
Rated Current: 0.315A
Rated Power: 3.78W
Speed: 8300 RPM
Airflow: 40.0 CFM / 1.13 m³/min
Static Pressure: 0.660 inch-H2O / 164.4 Pa
Noise Level: 46.0 dBA
Connector: 4-Wire Leads (PWM Control and Speed Sensor)
Bearing Type: Ball Bearing
Life Expectancy: High (typical for Sunon’s high-performance ball or Vapo bearings)
Operating Temperature: Not consistently specified in common listings (typical for DC fans is -10°C to 70°C)
Frame Material: Plastic
Impeller Material: Plastic
Features: PWM Control, Speed Sensor (Tachometer Output), Auto Restart
