R2A150-AC01-16 ebmpapst 230V 150mm AC Hot Air Blower

Description

The ebmpapst R2A150-AC01-16 is a high-performance 230 V industrial AC centrifugal blower with an impeller size of 150 mm and dimensions of 152 x 152 x 103 mm, purpose-built to deliver elite-level thermal cooling in high-resistance airflow paths. This unit features a heavy-duty single-phase motor capable of sustaining a 32 W power input to drive its specialized stainless steel impeller at a stable speed of 1800 RPM. Engineered specifically for air displacement in drying ovens and laboratory dry boxes, it utilizes a triangular mounting plate to provide balanced pressure and consistent airflow for mission-critical hardware. The mechanical design relies on precision maintenance-free ball bearings and a galvanized sheet steel frame to ensure reliable continuous operation across an ambient temperature range of -25 °C to 120 °C. Featuring a robust 2-pin flat terminal interface and Class H insulation, this blower is a critical component for sterilization cabinets, industrial heating systems, and climate chambers where long-term reliability and high-temperature resilience are mandatory.

R2A150-AC01-16 Fan Parameters
Manufacturer: ebmpapst
Model Number: R2A150-AC01-16
Motor Model: M2A068-AA
Series: AC Centrifugal Blower (Hot Air)
Impeller Size: 150 mm
Dimensions: 152 x 152 x 103 mm
Type: AC Centrifugal Blower
Bearing Type: Ball Bearing
Nominal Voltage: 230 VAC
Voltage Range: 200 – 240 VAC
Frequency: 50 Hz
Weight: 1150 g

[Electrical Data]
Input Power: 32 W
Nominal Current: 0.27 A
Nominal Speed: 1800 RPM
Required Capacitor: 1.0 µF / 400 VDB (Typically external)
Motor Design: AC motor with shaded-pole technology
Motor Protection: Thermal overload protector (TOP) wired internally
Insulation Class: Class H
Termination: 2 Flat Pin Terminals (6.3 x 0.8 mm)

[Performance & Acoustics]
Max. Air Flow: 105.9 CFM (180.0 m³/h / 3.0 m³/min)
Max. Static Pressure: 15.30 mmH₂O (150.0 Pa / 0.60 inH₂O)
Sound Pressure Level: 58 dB(A)
Direction of Rotation: Clockwise (Viewed toward rotor)
Airflow Direction: Radial (Centrifugal)
Mode of Operation: S1 (Continuous operation)

[Materials & Construction]
Impeller Material: Stainless steel
Mounting Plate Material: Sheet steel, galvanized
Housing Design: Triangular mounting plate
Installation Position: Shaft horizontal
Degree of Protection: IP20
Environmental Protection Class: H1

[Reliability & Safety Standards]
Min. Ambient Temperature: -25 °C
Max. Ambient Temperature: 120 °C (Motor side)
Max. Permissible Temp. (Impeller): 300 °C
Storage Temperature: -40 °C – 130 °C
Life Expectancy: 30,000 hours at 40 °C
Standard Compliance: EN 60335-1, CE
Approval Agency: VDE, CCC, CE

Application
The ebmpapst R2A150-AC01-16 hot air blower is used in industrial drying ovens, laboratory dry boxes, sterilization cabinets, climate simulation chambers, and food processing equipment.
