Description
Brand new German ebmpapst fan R2E133-BH66-07/14 230V air purification fan
Model:R2E133-BH66-07
Size:133mm
Voltage:AC 230V
Current:0.11/0.13A
Power: 25/28W
Air volume:240/280m3/h
Speed:2700/3200RPM
Noise:53/56dB(A)
Lifespan:50000h
Weight:0.59KG
Bearing structure: maintenance-free ball bearings
Wiring method: outlet type
Temperature range:-25℃ to+65℃
Frame leaves: high-grade metal
It is a replacement model for R2E133-BH66-14
The ebm-papst R2E133-BH66-07 is a robust AC backward curved centrifugal fan manufactured by ebm-papst, engineered for efficient air movement in applications demanding significant static pressure within compact spaces. Operating on 230V AC power at 50/60 Hz, it draws 0.11A (50Hz) / 0.13A (60Hz) of current, consuming 25W (50Hz) / 28W (60Hz) of power. With a 133mm impeller, it achieves speeds of 2700 RPM (50Hz) / 3200 RPM (60Hz), delivering substantial airflow. Its compact design and ability to generate high static pressure make it ideal for cooling electronics, integration into HVAC systems, and various industrial equipment where effective airflow against resistance is crucial. Equipped with durable ball bearings and an IP44 protection rating, it ensures reliable and long-lasting performance across an operating temperature range of -25°C to 65°C.
