R2E250-RB06-01 ebmpapst 230V AC Centrifugal Fan

Description

The ebmpapst R2E250-RB06-01 is a 230VAC AC centrifugal fan with dimensions of 250x117mm. Operating across both 50Hz and 60Hz frequencies, it draws 1.1A of current and consumes 250W of power at 50Hz, and 1.71A of current and 390W of power at 60Hz. This fan operates at speeds of 2750RPM at 50Hz and 3100RPM at 60Hz. Featuring durable ball bearings, a PA plastic impeller, and a galvanized steel housing, it boasts an IP54 ingress protection rating. It is suitable for reliable operation within an ambient temperature range of -25 to 60°C and has a typical service life of 40,000hours at 40°C.

R2E250-RB06-01 Fan Parameters
Manufacturer: ebmpapst
Model: R2E250-RB06-01
Fan Type: AC Centrifugal Fan
Dimensions: 250 x 117 mm
Rated Voltage: 230 VAC
Frequency: 50 Hz / 60 Hz
Current Rating: 1.1 A (50Hz), 1.71 A (60Hz)
Power Consumption: 250 W (50Hz), 390 W (60Hz)
Speed: 2750 RPM (50Hz), 3100 RPM (60Hz)
Bearing Type: Ball Bearing
Termination: Wire Leads
Operating Temperature: -25 ~ 60°C
Lifetime @ Temp: 40,000 Hours (at 40°C)
Housing Material: Galvanized steel
Blade Material: PA plastic
IP Rating: IP54
Weight: 3.8 kg
Approval Agency: CCC, EAC
Application: This ebmpapst AC centrifugal fan is highly suitable for demanding ventilation and air conditioning systems, industrial equipment, and applications requiring robust performance with specific power characteristics.
