Description
The ebmpapst R2E250-RB06-30 is a high-performance AC centrifugal fan, measuring 250mm in diameter, designed for a wide range of air intake applications. Operating at 230VAC with a dual frequency of 50Hz and 60Hz, it consumes 250W (1.1A) at 50Hz and 390W (1.71A) at 60Hz. This fan delivers a robust airflow of 900m³/h and a static pressure of 439Pa. It operates at speeds of 2750RPM (50Hz) and 3100RPM (60Hz). Featuring 7 blades and durable ball bearings, it boasts an IP44 ingress protection rating. It is suitable for reliable operation within an ambient temperature range of -25 to 75°C and is certified by CCC, UL, and CSA.
R2E250-RB06-30 Fan Parameters
Manufacturer: ebmpapst
Model: R2E250-RB06-30
Fan Type: AC Centrifugal Fan
Dimensions: 250 mm diameter
Rated Voltage: 230 VAC
Frequency: 50 Hz / 60 Hz
Current Rating: 1.1 A (50Hz), 1.71 A (60Hz)
Power Consumption: 250 W (50Hz), 390 W (60Hz)
Airflow: 900 m³/h
Static Pressure: 439 Pa
Speed: 2750 RPM (50Hz), 3100 RPM (60Hz)
Noise Level: 69 dB(A)
Bearing Type: Ball Bearing
Number of Blades: 7
Termination: Wire Leads
Operating Temperature: -25 ~ 75°C
Lifetime @ Temp: Not specified
Frame Material: Not specified
Blade Material: Plastic
IP Rating: IP44
Weight: 3.9 kg
Approval Agency: CCC, UL, CSA
Application: This ebmpapst AC centrifugal fan is suitable for air intake applications in various industrial settings, drive cooling systems, and general ventilation where high airflow and static pressure are required.
