Description
The ebmpapst R4E355-AL02-05 is a powerful 230V AC centrifugal fan with backward-curved blades, widely used as a motorized impeller. It has an impeller diameter of 355mm and overall dimensions of Ø360mm x 195mm. Operating at 230V AC with a frequency of 50Hz, it consumes 245W of power, drawing 1.12A of current, and spins at 1420 RPM. This fan delivers a substantial airflow of 3165 m³/h / 1865 CFM and operates with a noise level of 66 dBA. It is rated IP44 for protection, features robust ball bearings, and utilizes an aluminum impeller with a black-coated rotor surface, making it suitable for demanding ventilation tasks and applications such as medical clean FFU purification fans.
R4E355-AL02-05 Fan Parameters
Model Number: R4E355-AL02-05
Manufacturer: ebmpapst
Type: AC Centrifugal Fan / Motorized Impeller (Backward-Curved, Single Inlet)
Overall Dimensions: Ø360mm x 195mm
Impeller Diameter: 355mm
Rated Voltage: 230 VAC
Frequency: 50 Hz
Rated Current: 1.12A
Rated Power: 245W
Speed: 1420 RPM
Airflow (Free Air): 3165 m³/h / 1865 CFM
Static Pressure: Up to 420 Pa
Noise Level: 66 dBA
IP Rating: IP44
Connector: 4 Wire Leads
Bearing Type: Ball Bearing
Impeller Material: Aluminum
Rotor Surface: Black coated
Operating Temperature: -25°C to +50°C
Weight: 5.3 kg
Features: External rotor motor, Thermal Overload Protector, Impedance protected
Approvals/Certifications: CE, CCC
