SJ1225HD1 SANJUN 12V DC Axial Fan

Description

The SANJUN SJ1225HD1 is a compact and high-performance 12V DC Axial Fan with dimensions of 120x120x25mm, designed for robust cooling in various electronic systems. The SJ1225HD1 operates with a rated current of 0.19A and a power consumption of 2.28W. It achieves a high speed of 4200RPM, delivering a substantial airflow of 271.84m³/h (160CFM) with a high static pressure of 4509.69Pa (18.1INH2O). The fan produces a noise level of 56dB(A). Built with durable 2 ball bearings, the SJ1225HD1 ensures reliable long-term performance with a life expectancy of 50000 hours at 40°C. It features a plastic frame and impeller, comes with 2-wire termination, and includes auto-restart protection, making it suitable for applications such as computer cases, small appliances, industrial control panels, and other general electronic cooling needs requiring significant air movement.

SJ1225HD1 Fan Parameters
Model: SJ1225HD1
Manufacturer: SANJUN
Type: DC Axial Fan
Dimensions: 120 x 120 x 25 mm
Nominal Voltage: 12 V DC
Rated Current: 0.19 A
Power Consumption: 2.28 W
Speed: 4200 RPM
Airflow: 271.84 m³/h (160 CFM)
Static Pressure: 18.1 IN H2O (4509.69 Pa / 459.74 mmH2O)
Noise Level: 56 dB(A)
Weight: 126 g
Bearing Type: 2 Ball Bearing
Frame Material: Plastic
Impeller Material: Plastic
Min. Ambient Temperature: -10 °C
Max. Ambient Temperature: 70 °C
Life Expectancy: 50000 h at 40°C
Termination: 2-wire leads
Motor Protection: Auto-restart protection
Approval: CE, RoHS
Application: Computer cases, small appliances, industrial control panels, and general electronic cooling.
