Description
The SUNON UB5U3-700 is an ultra-compact DC Blower Fan from SUNON’s Mighty Mini series, engineered for high-performance cooling in tight spaces. Operating on 5V DC power, it draws 0.072A of current, consuming 0.36W of power. Measuring just 30mm x 30mm x 3mm, this miniature fan is ideal for cooling microprocessors, portable devices, and other compact electronics. It achieves a high speed of 9500 RPM, delivering an airflow of 0.636 CFM and generating significant static pressure at 0.354 inch-H2O. Despite its powerful performance for its size, it maintains a relatively low noise level of 25.6 dBA. Equipped with 2-wire leads and SUNON’s proprietary Vapo-Bearing System, it also features auto restart and polarity protection. With an IP55 rating, it offers protection against dust and water, making it suitable for a wide range of applications from -10°C to 70°C.
UB5U3-700 SUNON Jianzhuan 3004 micro-turbo blower fan 5V 30x3MM blowing and heat dissipation blower
Model Number: UB5U3-700
Manufacturer: SUNON
Type: DC Blower Fan
Rated Voltage: 5V DC
Operating Voltage Range: 2V to 6V DC
Rated Current: 0.072A
Rated Power: 0.36W
Speed: 9500 RPM
Airflow: 0.636 CFM
Static Pressure: 0.354 inch-H2O
Noise Level: 25.6 dBA
Dimensions: 30mm x 30mm x 3mm
Connector: 2-Wire Leads
Bearing Type: Vapo-Bearing System
Ingress Protection: IP55
Operating Temperature: -10°C to 70°C
Frame Material: Liquid Crystal Polymer
Impeller Material: Liquid Crystal Polymer
Features: Auto Restart, Polarity Protection, MagLev Motor Technology
