XA3010B12H XA-CQJ DC12V 0.12A axial fan

Description

The XA-CQJ XA3010B12H is a DC axial fan measuring 30x30x10mm. It operates on 12 VDC, drawing 0.12 A of current, with a power consumption of 1.44 W. This fan achieves a high speed of 10500 RPM, providing an airflow of 4.3 CFM and a static pressure of 0.176 inH2O. The noise level is 29.2 dB(A). It features a ball bearing for reliable operation and connects via 2 leads. Weighing 7.6 g, this compact fan is commonly used in electronic devices and applications where high airflow and static pressure are needed in a small footprint.

XA3010B12H Fan Parameters
Model: XA3010B12H
Manufacturer: XA-CQJ
Type: DC Axial Fan
Dimensions: 30x30x10 mm
Rated Voltage: 12 VDC
Rated Current: 0.12 A
Power Consumption: 1.44 W
Speed: 10500 RPM
Airflow: 4.3 CFM
Static Pressure: 0.176 inH2O
Noise Level: 29.2 dB(A)
Bearing Type: Ball Bearing
Termination: 2 Leads
Weight: 7.6 g
Application: Compact electronic devices.
