Description
The XIANGYU XY-12038B2H is an EC axial fan measuring 120x120x38mm. It is designed for wide voltage compatibility, operating on 110-240 VAC at 50/60 Hz frequencies. It typically draws 0.07 A of current, with a power consumption of 2.33 W. This fan achieves a high speed of 4800 RPM. The noise level is 40 dB(A). It features double ball bearings for durability and a longer lifespan. The fan connects via 2-wire Leads. This fan is commonly utilized in various cabinet and case cooling applications, providing high air volume with energy-saving EC technology.
XY-12038B2H Fan Parameters
Model: XY-12038B2H
Manufacturer: XIANGYU GROUP Fan
Type: EC Axial Fan
Dimensions: 120x120x38 mm
Rated Voltage: 110-240 VAC
Frequency: 50 Hz / 60 Hz
Rated Current: 0.07 A
Power Consumption: 2.33 W
Speed: 4800 RPM
Noise Level: 40 dB(A)
Bearing Type: Double Ball Bearing
Termination: 2-wire Leads
Application: Cabinet cooling, general case cooling.
