Description
The Fasco Z40AA07A01 GPM10.0 is a high-capacity 208-240V Centrifugal Blower specifically engineered for mission-critical forced draft applications in large-scale Premix Low-NOx Condensing Steam Generators and burner systems. Driven by a specialized high-speed motor with reinforced double ball bearings, this heavy-duty unit operates on a 208 – 240 VAC supply delivering a Max. Power Consumption of 1200 W and a Max. Current Draw of 5.2 A at a rated speed of 4900 RPM. This High-performance unit is optimized to overcome significant static pressure in condensing heat exchangers, providing a Max. Air Flow of 547.4 CFM (930.0 m³/h / 15.50 m³/min) and a Max. Static Pressure of 326.31 mmH₂O (3200.0 Pa / 12.85 inAq). Featuring intelligent speed regulation via PWM/0-10V control input, soft start, and locked-rotor protection, this 42-blade unit with die-cast aluminum construction ensures precise gas-air premixing and high operational reliability in intense thermal environments at the end.
Z40AA07A01 GPM10.0 Fan Parameters
Model Number: Z40AA07A01 GPM10.0
Manufacturer: Fasco
Type: Centrifugal Blower (Premix Burner Blower)
Impeller Size: 180 mm
Weight: 7.2 kg
Bearing Type: Ball bearing
Phase: 1~
Nominal Voltage: 230 VAC
Nominal Voltage Range: 208 – 240 VAC
Frequency: 50 / 60 Hz
Max. Current Draw: 5.2 A
Max. Power Consumption: 1200 W
Rated Speed: 4900 RPM
Max. Air Flow: 547.4 CFM (930.0 m³/h / 15.50 m³/min)
Max. Static Pressure: 326.31 mmH₂O (3200.0 Pa / 12.85 inAq)
Working Air Flow: 930.0 m³/h
Static Pressure Increase: 3200.0 Pa
Control Interface: PWM (0.1 – 6.0 kHz) / 0-10 VDC
Output Signal: Tach output (Speed signal)
Number of Blades: 42 (Forward curved)
Technical Features: Soft start; Motor current limitation; Locked-rotor protection; Over-temperature protected electronics
Motor Protection: Electronic motor protection
Touch Current (IEC 60990): ≤ 3.5 mA
Insulation Class: “B”
Degree of Protection: IP44
Protection Class: I (if protective earth is connected)
Impeller Material: Sheet steel / Aluminum
Housing Material: Die-cast aluminum
Direction of Rotation: Clockwise (viewed from motor side)
Installation Position: Any
Mode: S1
Ambient Temperature (Max.): 60 °C
Min. Operating Temperature: -20 °C
Standard Compliance: EN 60335-1; CE
Approval: CCC; CE; UL
Application
The Fasco Z40AA07A01 GPM10.0 blower is the primary forced-draft component for large-scale premix low-NOx condensing steam generators and burner systems requiring high-volume modulation and massive static pressure for efficient air-fuel mixing.
