130FLJ1-22 Bedeldo centrifugal fan 220V 85W blower

Description

Product Type: Centrifugal Fan
Model: 130FLJ1
Operating Voltage: 220V / 230V AC
Frequency: 50Hz
Rated Power: 85W
Rated Current: Approximately 0.37A – 0.4A slight variations between sources
Speed: Approximately 2200 RPM – 2500 RPM slight variations between sources
Air Flow: Approximately 216 m³/h or 3.6 m³/min Please note that one source mentioned 700 m³/h, but this differs significantly from other sources and might be for a different model or a data error
Static Pressure: 280 Pa
Noise: ≤70 dB(A) or 70 dB(A)
Capacitor: 2.2μF typically rated for 500V
Motor Type: Single-phase asynchronous motor
Bearing Type: Ball Bearing mentioned in one source
Material: Copper wire motor, carbon steel housing, metal impeller mentioned in different sources
Approximate Dimensions: 183mm x 235mm x 110mm overall dimensions mentioned in one source, other sources provide installation dimension diagrams but no specific value list
Weight: Approximately 2.5 kg – 2.6 kg slight variations between sources, package weight may be higher
Operating Temperature Range: -10°C to 65°C mentioned in one source
130FLJ1-22 Bedeldo wing centrifugal fan 220V 85W blower vortex fan
