Description
The ebmpapst 3412NGME is a compact and efficient 92mm DC axial cooling fan, engineered for reliable performance in a wide array of electronic and industrial applications. Operating on 12V DC, it provides a balanced airflow with a notably low noise level for its class. This fan features Sintec sleeve bearings, which are designed for quiet operation and a long service life, especially at moderate temperatures. It also includes built-in protection against reverse polarity and a blocked rotor, enhancing its durability and safety in various systems. It connects via 2-wire leads for straightforward power input.
Product Specifications: ebmpapst 3412NGME Cooling Fan
Model: 3412NGME
Manufacturer: ebmpapst
Type: Axial Fan
Fan Dimensions: 92mm x 92mm x 25mm
Rated Voltage: DC 12V
Operating Voltage Range: DC 8V to 15V
Rated Current: 0.133A
Rated Power: 1.6W
Maximum Rotational Speed: 2300 RPM
Maximum Airflow: 42.4 CFM (72 m³/h)
Noise Level: 28 dBA
Bearing Type: Sintec Sleeve Bearing
Expected Lifespan: 75,000 hours (at 40°C); 27,500 hours (at max temperature, 75°C)
Connector: 2-Wire Leads
