Description
The NMB-MAT 4715MS-23T-B5A is a high-performance 230V AC axial fan measuring 119x119x38mm. It’s well-regarded for its exceptional reliability and long operational lifespan, thanks to its ball bearing design. This fan delivers a robust airflow of approximately 88.2 to 102 CFM while maintaining a relatively low noise level of 37 to 41 dBA. It’s an ideal cooling solution for various industrial and electronic applications, including equipment cabinets, UPS power supplies, and frequency converters, ensuring the stable operation of critical systems.
4715MS-23T-B5A brand new NMB 12038 230V UPS cooling fan 12 cm axial flow fan
Model:4715MS-23T-B5A
Manufacturer: NMB-MAT
Type: AC Axial Fan
Dimensions: 119 x 119 x 38 mm
Nominal Voltage: 230V AC
Frequency: 50/60 Hz
Power Consumption: 14W to 15W
Current: 0.10A to 0.12A
Speed: 2600 to 2900 RPM
Airflow: 88.2 to 102 CFM
Static Pressure: 0.26 to 0.28 In H2O
Noise Level: 37 to 41 dBA
Bearing Type: Ball Bearing
Life Expectancy: 50,000 to 100,000 hours
Housing Material: Aluminum
Impeller Material: Polycarbonate
Termination: 2 Quick Connect Terminals
Protection: Impedance protected
Operating Temperature: -10°C to 70°C
