AD0812HB-A70GL ADDA 12V DC Axial Fan

Description

The ADDA AD0812HB-A70GL is a high-speed 12VDC axial fan with dimensions of 80x80x25mm. It is designed to provide efficient cooling, moving 38.6CFM (65.57m³/h) of air and generating up to 0.160inchH₂O (39.9Pa) of static pressure while operating at a speed of 3010RPM. This fan consumes 3.0W of power and draws 0.25A of current. It incorporates durable ball bearings and is constructed from fire-retardant plastic material. It uses a two-wire termination and operates within an extended temperature range of -20 °C to 80 °C. It is commonly used for cooling components in PCs, networking hardware, power supplies, and various general-purpose electronic enclosures.

AD0812HB-A70GL Fan Parameters
Manufacturer: ADDA
Model: AD0812HB-A70GL
Fan Type: DC Axial Fan
Dimensions: 80 x 80 x 25 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 6.0 ~ 13.8 VDC
Current Rating: 0.25 A
Power Consumption: 3.0 W
Airflow: 38.6 CFM (65.57 m³/h)
Static Pressure: 0.160 inch H₂O (39.9 Pa)
Speed: 3010 RPM
Noise Level: 34.4 dB(A)
Bearing Type: Ball Bearing
Termination: Two Wire Leads
Housing Material: Plastic (UL94V-0)
Impeller Material: Plastic (UL94V-0)
Operating Temperature: -20 °C ~ 80 °C
Lifetime @ Temp: 70,000 Hours @ 40 °C
Weight: 77 g
Application: This ADDA DC axial fan is suitable for cooling PCs, networking hardware, power supplies, and electronic enclosures.
