BD126018HB Y.S.Tech 12V 0.35A DC Blower

Description

The Y.S. Tech BD126018HB is a high-performance DC Blower with measuring dimensions of 60 x 60 x 18 mm. It operates on a rated voltage of 12 VDC with a maximum current draw of 0.35 A and an input power of up to 4.2 W. This high-speed blower achieves 5400 RPM, delivering an airflow of 13.93 m³/h (8.2 CFM). Utilizing 2 Ball Bearings for reliability, this fan features a 3-Wire termination (typically for speed monitoring) and is ideal for focused cooling applications in tight enclosures, networking equipment, and industrial controls where precise airflow and a compact size are critical.

BD126018HB Fan Parameters
Model: BD126018HB
Manufacturer: Y.S. Tech
Type: DC Blower
Dimensions: 60 x 60 x 18 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 7 ~ 13.2 VDC
Rated Current: 0.28 A
Max. Current: 0.35 A
Rated Input Power: 3.36 W
Max. Input Power: 4.2 W
Speed: 5400 RPM
Airflow: 13.93 m³/h
Noise Level: 49 dB(A)
Bearing Type: 2 Ball Bearing
Termination: 3-Wire Leads

Application
The BD126018HB is primarily used for spot cooling, forced air circulation, or in systems where high static pressure is needed to overcome resistance from dense components or ducting. Typical applications include server rack units, telecom base stations, network routers, and embedded industrial PCs.
