Description
The NIDEC D350 is a digital automatic voltage regulator for alternators, providing a rated excitation current of 5 A. It is known for its excellent reliability and advanced protection functions, including over-excitation limitation and voltage sensing loss. It is designed to work with various excitation types, such as SHUNT, AREP, or PMG, and is used for generator sets to ensure stable power output.
Product Parameters
Manufacturer: NIDEC
Model: D350
Type: Digital Automatic Voltage Regulator
Rated Excitation Current: 5 A
Technology: Digital
Excitation Mode: SHUNT, AREP, PMG
Regulation Accuracy: ±0.25 %
Frequency Range: 10 – 100 Hz
Operating Temperature: -40 °C to +65 °C
Measuring: 140 x 125 x 52.9 mm
Application
The D350 is used in industrial alternators and generator sets. It is specifically designed for managing short-circuits and load impacts, and it features functions for parallel operation of multiple generators.
