Description
The SUNON MB40201VX-000C-A99 is a high-performance 12VDC axial fan with compact dimensions of 40x40x20mm. It is designed for robust cooling in tight spaces, providing 10.8CFM (18.4m³/h) of airflow and generating 0.27inchH₂O (67.3Pa) of static pressure while operating at 8200RPM. The fan consumes 1.38W of power and draws 0.115A of current. It is highly reliable, utilizing Sunon’s proprietary Vapo bearing for a long lifespan. The fan is terminated with two wire leads for standard power connection. It is commonly used for cooling processors, server components, power supplies, and other compact electronic devices.
MB40201VX-000C-A99 Fan Parameters
Manufacturer: SUNON
Model: MB40201VX-000C-A99
Fan Type: DC Axial Fan
Dimensions: 40 x 40 x 20 mm
Rated Voltage: 12 VDC
Current Rating: 0.115 A
Power Consumption: 1.38 W
Airflow: 10.8 CFM (18.4 m³/h)
Static Pressure: 0.27 inch H₂O (67.3 Pa)
Speed: 8200 RPM
Noise Level: 27.5 dB(A)
Bearing Type: Vapo Bearing
Termination: Two Wire Leads
Housing Material: Plastic
Impeller Material: Plastic
Operating Temperature: -10 °C ~ 70 °C
Weight: 31 g
Application: This SUNON DC axial fan is suitable for cooling processors, server components, and power supplies.
